Series 2000 Magnehelic® Differential Pressure Gages

Series 2000 Magnehelic® Differential Pressure Gages

Service
  • Air and non-combustible, compatible gases(natural gas option available).
  • Note: May be used with hydrogen. Order a Buna-diaphragm. Pressures must be less than 35 psi

Applicable standards

TypeMagnehelic & Digital Gauges
Model Name2000
Wetted MaterialsConsult factory.
HousingDie-cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168-hour salt spray corrosion test.
Accuracy±2% (-HA model ±1) of FS (±3% (-HA ±1.5%) on -0, -100PA, -125PA, -10MM and ±4% (-HA ±2%) on -00, -60PA, -6MM ranges), through out range at 70°F (21.1°C).
Pressure Limits-20 in Hg. to 15 psig.† (-0.677 bar to 1.034 bar)| MP option: 35 psig (2.41 bar) | HP option : 80 psig (5.52 bar)
Enclosure RatingIp 67
Over PressureThe relief plug opens at approximately 25 psig (1.72 bar), standard gages only. See Overpressure Protection note on Catalog page
Temperature Limits20 to 140°F (-6.67 to 60°C) | -20°F (-28°C) with low temperature option
Size4″ (101.6 mm) diameter dial face.
Mounting OrientationThe diaphragm in vertical position. Consult factory for other position orientations
Process Connections1/8″ female NPT duplicate high and low-pressure taps – one pair side and one pair back.
Weight1 lb 2 oz (510 g) | MP & HP 2 lb 2 oz (963 g).
Standard AccessoriesTwo 1/8″ NPT plugs for duplicate pressure taps, two 1/8″ pipe thread to rubber tubing adapters, and three flush mounting adapters with screws. (Mounting and snap ring retainer substituted for three adapters in MP & HP gage accessories.)
